Description
MAIN STANDARD CHARACTERISTICS
- Automatic unwinder (different models for any need)
- Primer/Release coating and drying unit
- Rotogravure system with “closed chambre doctor blade” or Mayer bar
- Primer/release feeding and recycle systems with tanks and pumps
- Vertical or horizontal hot air drying ovens with thermal blower modules
- Adhesive coating unit
- Coating head: rotating knife type, with knife and applicator rolls, parallel or overlapped arranged, prearranged for automatic correction
- Vacuum driven pull in exit
- Adhesive drying tunnel
- High efficiency horizontal ovens, shall opening type, film conveyance by means of idle or driven rolls
- Thermal blower modules: integrated or separated
- Each module can be dedicated to 1 or 2 sections of ovens
- Air heating with thermal oil, steam or overheated water batteries, or gas burners
- Equipment and devices for solvent prevention
- Insulating cabinets
- LEL monitoring systems (I.R. or Flame Temp. Analyser type)
- Draw and cooling unit with water cooled cylinders
- Anti-surface treatment
- For coating units inside frames and after coating web contact rolls. Eventually for nozzles and rolls inside release/primer/adhesive drying ovens.
- Automatic winder (different models for any need)
- Equipment and devices for the good control of the web
- (Spreader rolls, antistatic devices, tension control devices…)
FITTING AND OPTIONS
Coating line can be equipped with:
- Reels loading-unloading systems
- Film stretching calenders group
- Corona treatment stations
- Other type of applicable adhesive coating heads
- Mayer bar, reverse roll, “comma” roll system…
- Other types of drying ovens:
- Both sides vertical opening type, air flotation type, driven conveyor belts type…
- Heat exchangers for energy recovery
- High temperature curing ovens
- Humidification system
- Secondary unwinder with lamination group
- Delaminating group with liner rewinder
- Web pre-conditioning groups: heated calenders or I.R. plates
- Web cleaning treaters
- Web surface inspection and monitoring system
- Coat thickness/basis-weight measuring system:
- Total basis weight type or differential synchronized measuring type, with eventually automatic adjustment of the coating die
- Supervision system with industrial PC
Main standard characteristics
• Automatic unwinder (different models for any need)
• Primer/Release coating and drying unit
Rotogravure system with “closed chambre doctor blade” or Mayer bar
Primer/release feeding and recycle systems with tanks and pumps
Vertical or horizontal hot air drying ovens with thermal blower modules
• Adhesive coating unit
Coating head: rotating knife type, with knife and applicator rolls, parallel or overlapped arranged, prearranged for automatic correction
Vacuum driven pull in exit
• Adhesive drying tunnel
High efficiency horizontal ovens, shall opening type, film conveyance by means of idle or driven rolls
Thermal blower modules: integrated or separated
– Each module can be dedicated to 1 or 2 sections of ovens
– Air heating with thermal oil, steam or overheated water batteries, or gas burners
• Equipment and devices for solvent prevention
Insulating cabinets
LEL monitoring systems (I.R. or Flame Temp. Analyser type)
• Draw and cooling unit with water cooled cylinders
• Anti-surface treatment
For coating units inside frames and after coating web contact rolls. Eventually for nozzles and rolls inside release/primer/adhesive drying ovens.
• Automatic winder (different models for any need)
• Equipment and devices for the good control of the web
(Spreader rolls, antistatic devices, tension control devices…)
Fittings and options
Coating line can be equipped with:
• Reels loading-unloading systems
• Film stretching calenders group
• Corona treatment stations
• Other type of applicable adhesive coating heads
Mayer bar, reverse roll, “comma” roll system…
• Other types of drying ovens:
Both sides vertical opening type, air flotation type, driven conveyor belts type…
• Heat exchangers for energy recovery
• High temperature curing ovens
• Humidification system
• Secondary unwinder with lamination group
• Delaminating group with liner rewinder
• Web pre-conditioning groups: heated calenders or I.R. plates
• Web cleaning treaters
• Web surface inspection and monitoring system
• Coat thickness/basis-weight measuring system:
Total basis weight type or differential synchronized measuring type, with eventually automatic adjustment of the coating die
• Supervision system with industrial PC
